Tempat asal:
Shanghai, Cina
Nama merek:
carterberg
Sertifikasi:
IATF16949
Nomor model:
CB-4
Aplikasi: Seri ISO5675 membawa ke industri desain terbukti untuk digunakan pada peralatan konstruksi, Perkakas kehutanan, mesin pertanian, alat minyak, mesin pabrik baja,dan aplikasi hidraulik lainnya yang menuntut.
Spesifikasi:
| Ukuran tubuh (dalam) | 1/2 | ||||
| Tekanan nominal (PSI) | 4000 | ||||
| Aliran Nominal (GPM) | 12 | ||||
| Rentang suhu (std seal) | -20°C sampai +120°C | ||||
| Bahan segel standar | NBR | ||||
Fitur
|
Teman. |
LS |
¢D |
HEX1 |
T |
|
CB-S5-04SF3/8 |
66 |
38 |
27 |
3/8BSP NPT3/8 |
|
CB-S5-04SF1/2 |
66 |
38 |
27 |
1/2BSP NPT1/2 |
|
CB-S5-04SF3/4 |
69 |
38 |
34 |
3/4BSP NPT3/4 |
|
CB-S5-04SFM14 |
66 |
38 |
27 |
M14*1.5 |
|
CB-S5-04SFM16 |
66 |
38 |
27 |
M16*1.5 |
|
CB-S5-04SFM18 |
66 |
38 |
27 |
M18*1.5 |
|
CB-S5-04SFM22 |
66 |
38 |
27 |
M22*1.5 |
|
Teman. |
LP |
d |
C |
HEX2 |
T |
|
CB-S5-04PF3/8 |
61.5 |
20.5 |
27 |
27 |
3/8BSP NPT3/8 |
|
CB-S5-04PF1/2 |
44 |
20.5 |
27 |
27 |
1/2BSP NPT1/2 |
|
CB-S5-04PF3/4 |
64.5 |
20.5 |
34 |
34 |
3/4BSP NPT3/4 |
|
CB-S5-04PFM14 |
61.5 |
20.5 |
27 |
27 |
M14*1.5 |
|
CB-S5-04PFM16 |
61.5 |
20.5 |
27 |
27 |
M16*1.5 |
|
CB-S5-04PFM18 |
61.5 |
20.5 |
27 |
27 |
M18*1.5 |
|
CB-S5-04PFM22 |
44 |
20.5 |
27 |
27 |
M22*1.5 |
